Introduction
XS160A/XS190A/XS220A Vibratory roller is the
heavy self-propelled single-drum vibratory
roller,which is mainly suited for compaction
during constructions of high-class highways,airports,harbours,dams
and industrial yards,Also lends itself to
be used on the large-scale base course,sub-base
and embankment fill compaction. The machine
has original high-power engine and special
hydraulic driving system,which can make the
machine fit with construction work better
in areas of plateau and desert.
XS160A/XS190A/XS220A Vibratory roller takes
its main components and system according to
international style. It has following described
advantages in its structure and performance:
Four-level infinitely speeding of closed hydraulic
driving system,double frequency and double
amplitude,wholly closed air-conditioned driving
cab,the operating system which fulfills the
ergonomical principle,suspensional seat,hydraulic
articulated steering and the configuration
of stream line.
Main technical specification
| |
XS140 |
XS160 |
XS180 |
| Working mass(Kg) |
14700 |
16800 |
18100 |
| Module mass on front drum(Kg) |
9000 |
10700 |
12000 |
| Module mass on rear wheels(Kg) |
5700 |
6100 |
6100 |
| Static liner load(N/cm) |
425 |
492 |
552 |
| Speed range(Km/h) |
0-12 |
0-12 |
0-12 |
| Gradeability(%) |
50 |
55 |
55 |
| Min. turning radius(mm) |
5900 |
6320 |
6320 |
| Min.clearance(mm) |
460 |
450 |
450 |
| Max.protuberating(mm) |
130 |
150 |
150 |
| Steering angle |
±38° |
±33° |
±33° |
| Swinging angle |
±9° |
±9° |
±9° |
| Vibrating frequcncy(low/high)(Hz) |
28/35 |
28/38 |
28/35 |
| Norminal amplitude @ low/high frequency(mm) |
1.80/0.77 |
1.80/0.79 |
1.80/0.79 |
| Centrifugal force@ low frequency
high amplitude/high frequency high
amplitude(kN) |
330/220 |
350/240 |
375/250 |
| Vibrating drum diameter(mm) |
1520 |
1523 |
1600 |
| Vibrating drum width(mm) |
2130 |
2130 |
2130 |
| Engine |
|
|
|
| Model |
Cummins B5.9-C |
Deutz BF6L913 |
Deutz BF6L913C |
| Type |
Water cooling turbo-charged |
Air cooling
,turbo-charged |
| Max.Power@2500r/min(kW) |
113 |
118 |
141 |
| Total length(mm) |
6130 |
6295 |
6295 |
| Total width(mm) |
2390 |
2430 |
2430 |
| Total height(mm) |
3165 |
3188 |
3188 |
XS160A/XS190A/XS220A
roller can be equipped with the following
in case of need:
* Imported compaction meter.
* Padfooted drum.
* Air-cool diesel engine
