Max.Rated Lifting Capacity	kg	12000
Max.Lifting Height	m	21
Main Boom	m	3 sections 8.6-21
Jib	m	,
Max.Hoisting Moment	kN.m	410
Max.Lifting Speed(single rope)	m/min	70
Slewing Speed	r/min	≤2.3
Outline Dimension	m	10.2×2.5×3.2
Weight Data	t	16.02
Chassis Model	,	Self-made XZ12
Diesel Model	,	D6114ZG33A Hangzhou X6130
Max.Power of engline	kw/rpm	152/2200 154/2200
Max.Torque of engine	N.m/rpm	790/1400 780/1300
Min.Turing Radius	m	9
Max.Gradeabilitg	%	26
Max.Travel Speed	km/h	68
Approach Angle	°	21
Angle of Departure	°	10.7
Outriggers Distance(longitudinalXlateral)	m	3.98×4.8
