MAIN SPECIFICATION:
(The
information contained in this document is
subject to change without notice)
| Max
lift capacity |
2000 |
kg |
Oil
tank capacity |
25 |
L |
| Max
lift moment |
4 |
t.m |
Slewing
angle |
370° |
|
| Power
recommended |
5.05 |
kw |
Crane
weight |
850 |
kg |
| Max
flow of hydraulic system |
20 |
L/min |
Installation
space |
850 |
mm |
| Rated
pressure of hydraulic system |
22 |
MPa |
